MSI B650M BOMBER WIFI MOTHERBOARD 911-7E30-013
LKR54,500.00
MSI B650M PROJECT ZERO MOTHERBOARD D5 911-7E09-010
LKR88,000.00
MSI B650M GAMING PLUS WIFI DDR5 MOTHERBOARD 911-7E24-013
LKR69,000.00
03 Years Warranty
Description
Description
| CHIPSET | AMD B650 | |
| CPU | Supports AMD Ryzen™ 7000 Series Desktop Processors | |
| Socket AM5 | ||
| MEMORY | 4x DDR5, Maximum Memory Capacity 192GB | |
| Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz | ||
| Max. overclocking frequency: | ||
| • 1DPC 1R Max speed up to 7200+ MHz | ||
| • 1DPC 2R Max speed up to 6000+ MHz | ||
| • 2DPC 1R Max speed up to 6000+ MHz | ||
| • 2DPC 2R Max speed up to 5400+ MHz | ||
| Supports Dual-Channel mode | ||
| Supports non-ECC, un-buffered memory | ||
| Supports AMD EXPO | ||
| ONBOARD GRAPHICS | 1x HDMI™ | |
| Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz* | ||
| 1x DisplayPort | ||
| Supports DP1.4, maximum resolution of 4K 60Hz* | ||
| *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. | ||
| SLOT | 2x PCI-E x16 slot | |
| 1x PCI-E x1 slot | ||
| PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) | ||
| PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) | ||
| PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) | ||
| MULTI-GPU | AMD MULTI-GPU Support | |
| STORAGE | 2x M.2 | |
| M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280 devices | ||
| M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices | ||
| 4x SATA 6G | ||
| RAID | Supports RAID 0, RAID 1 and RAID 1 for SATA storage devices | |
| Supports RAID 0 and RAID 1 for M.2 NVMe storage devices | ||
| USB | 4x USB 2.0 (Front) | |
| 4x USB 3.2 Gen1 Type A (Rear) | ||
| 2x USB 3.2 Gen1 Type A (Front) | ||
| 3x USB 3.2 Gen2 Type A (Rear) | ||
| 1x USB 3.2 Gen2 Type C (Front) | ||
| 1x USB 3.2 Gen2x2 Type C (Rear) | ||
| LAN | Realtek® 8125BG 2.5G LAN | |
| WIRELESS LAN & BLUETOOTH | AMD Wi-Fi 6E | |
| The Wireless module is pre-installed in the M.2 (Key-E) slot | ||
| Supports MU-MIMO TX/RX | ||
| Supports 20MHz, 40MHz, 80MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands | ||
| Supports 802.11 a/ b/ g/ n/ ac/ ax | ||
| Supports Bluetooth® 5.3** | ||
| * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11. | ||
| ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. | ||
| AUDIO | Realtek® ALC897 Codec | |
| 7.1-Channel High Definition Audio | ||
| INTERNAL IO | 1x Power Connector(ATX_PWR) | |
| 2x Power Connector(CPU_PWR) | ||
| 1x CPU Fan | ||
| 1x Pump Fan | ||
| 4x System Fan | ||
| 2x Front Panel (JFP) | ||
| 1x Chassis Intrusion (JCI) | ||
| 1x Front Audio (JAUD) | ||
| 1x Com Port (JCOM) | ||
| 1x Tuning Controller connector(JDASH) | ||
| 2x Addressable V2 RGB LED connector (JARGB_V2) | ||
| 2x RGB LED connector(JRGB) | ||
| 1x TPM pin header(Support TPM 2.0) | ||
| 4x USB 2.0 ports | ||
| 2x USB 3.2 Gen1 Type A ports | ||
| 1x USB 3.2 Gen2 Type C ports | ||
| LED FEATURE | 4x EZ Debug LED | |
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit | |
| PCB INFO | ATX | |
| 243.84mmx304.8mm |
