ViewSonic 19″ Monitor VA1903h
- Display
Display Size (in.): 19 Viewable Area (in.): 18.5 Panel Type: TN Technology Resolution: 1366 x 768 Resolution Type: WXGA (Wide XGA) Static Contrast Ratio: 600:1 (typ) Dynamic Contrast Ratio: 50M:1 Light Source: LED Brightness: 200 cd/m² (typ) Colors: 16.7M Color Space Support: 8 bit (6 bit + FRC) Aspect Ratio: 16:9 Response Time (Typical Tr+Tf): 5ms Viewing Angles: 90º horizontal, 65º vertical Backlight Life (Hours): 30000 Hrs (Min) Curvature: Flat Refresh Rate (Hz): 60 Blue Light Filter: Yes Flicker-Free: Yes Color Gamut: NTSC: 72% size (Typ) sRGB: 102% size (Typ) Pixel Size: 0.3 mm (H) x 0.3 mm (V) Surface Treatment: Anti-Glare, Hard Coating (3H)
- Compatibility
PC Resolution (max): 1366x768 Mac® Resolution (max): 1366x768 PC Operating System: Windows 10/11 certified; macOS tested Mac® Resolution (min): 1366x768
- Connector
VGA:Â 1 3.5mm Audio Out:Â 1 HDMI 1.4:Â 1 Power in:Â 3-pin Socket (IEC C14 / CEE22)
- Power
Eco Mode (Conserve):Â 9.5W Eco Mode (optimized):Â 12.5W Consumption (typical):Â 15.3W Consumption (max):Â 17W Voltage:Â AC 100-240V Stand-by:Â 0.5W Power Supply:Â Internal Power Supply
- Additional Hardware
Kensington Lock Slot:Â 1
- Controls
Physical Controls:Â Auto, Left, Right, Menu, Power On Screen Display:Â Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall
- Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C) Humidity (non-condensing): 20% to 90%
- Wall Mount
VESA Compatible:Â 75 x 75 mm
- Input Signal
Frequency Horizontal:Â RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz Frequency Vertical:Â RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 75Hz
- Video Input
Digital Sync:Â TMDS - HDMI (v1.4) Analog Sync:Â Separate - RGB Analog
- Ergonomics
Tilt (Forward/Back): -3º / 18º
- Weight (imperial)
Net (lbs):Â 4.6 Net Without Stand (lbs):Â 4 Gross (lbs):Â 6.6
- Weight (metric)
Net (kg):Â 2.1 Net Without Stand (kg):Â 1.8 Gross (kg):Â 3
- Dimensions (imperial) (wxhxd)
Packaging (in.):Â 19.8 x 13.7 x 4.1 Physical (in.):Â 17.2 x 13.5 x 6.7 Physical Without Stand (in.):Â 17.2 x 10.7 x 1.9
- Dimensions (metric) (wxhxd)
Packaging (mm):Â 502 x 349 x 105 Physical (mm):Â 438 x 344 x 170 Physical Without Stand (mm):Â 438 x 271 x 48
- General
Regulations:Â cTUVus, FCC-B, ICES003, CEC, IQC-ST, MX-CoC, Mexico Energy, CB, RoHS, WEEE, BIS PACKAGE CONTENTS:Â VA1903H x1, 3-pin Plug (IEC C13 / CEE22) x1, VGA Cable (Male-Male) x1, Quick Start Guide x1 Recycle/Disposal:Â Please dispose of in accordance with local, state or federal laws. Warranty:Â *Warranty offered may differ from market to market
ViewSonic 22″ IPS Display Monitor VA2209-H
Display
Display Size (in.): 22
Viewable Area (in.): 21.5
Panel Type: IPS Technology
Resolution: 1920 x 1080
Resolution Type: FHD (Full HD)
Static Contrast Ratio: 1,000:1 (typ)
Dynamic Contrast Ratio: 50M:1
Light Source: LED
Brightness: 250 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit (6 bit + FRC)
Aspect Ratio: 16:9
Response Time (MPRT): 1ms
Viewing Angles: 178º horizontal, 178º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 100
Variable Refresh Rate Technology: Yes
Blue Light Filter: Yes
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 104% size (Typ)
Pixel Size: 0.249 mm (H) x 0.241 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H)
Compatibility
PC Resolution (max): 1920x1080
Mac® Resolution (max): 1920x1080
PC Operating System: Windows 10/11 certified; macOS tested
Mac® Resolution (min): 1920x1080
Connector
VGA: 1
3.5mm Audio Out: 1
HDMI 1.4: 1
Power in: DC Socket (Center Positive)
Power
Eco Mode (Conserve): 16W
Eco Mode (optimized): 18W
Consumption (typical): 20W
Consumption (max): 22W
Voltage: AC 100-240V
Stand-by: 0.3W
Power Supply: External Power Adaptor
Additional Hardware
Kensington Lock Slot: 1
Controls
Physical Controls: Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power)
On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90%
Wall Mount
VESA Compatible: 100 x 100 mm
Input Signal
Frequency Horizontal: RGB Analog: 24 ~ 86KHz, HDMI (v1.4): 30 ~ 115KHz
Frequency Vertical: RGB Analog: 48 ~ 75Hz, HDMI (v1.4): 48 ~ 100Hz
Video Input
Digital Sync: TMDS - HDMI (v1.4)
Analog Sync: Separate - RGB Analog
Ergonomics
Tilt (Forward/Back): -3º / 20º
Weight (imperial)
Net (lbs): 5.1
Net Without Stand (lbs): 4.2
Gross (lbs): 7.3
Weight (metric)
Net (kg): 2.3
Net Without Stand (kg): 1.9
Gross (kg): 3.3
Dimensions (imperial) (wxhxd)
Packaging (in.): 21.5 x 15.6 x 4.7
Physical (in.): 19.3 x 15 x 7.4
Physical Without Stand (in.): 19.3 x 11.5 x 1.6
Dimensions (metric) (wxhxd)
Packaging (mm): 545 x 395 x 120
Physical (mm): 491 x 381 x 189
Physical Without Stand (mm): 491 x 291 x 39
General
Regulations: RoHS, WEEE, BSMI, TGM, BIS
PACKAGE CONTENTS: VA2209-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Warranty: *Warranty offered may differ from market to market
